1. Definition and core functions

The Lifting trolley that can be put on the car is a mobile device that combines cargo transportation and height adjustment functions. It can lift and lower the platform through electric scissor lift table, and is suitable for short-distance handling scenarios that require frequent loading and unloading. Its core advantage lies in its foldable design and adaptability to transport vehicles, which significantly improves operating efficiency.

2. Main types and drive methods

Hydraulic drive type: Use manual or electric hydraulic pump to control lifting and lowering, with a load range of 500kg-3T, suitable for loading and unloading of small cargoes (such as tool boxes, building materials).

Electric drive type: Equipped with a battery powered system, supports trackless self-traveling and remote control, suitable for flat ground scenes such as workshops and warehouses, with a load capacity of 100kg-1T.

Representative product: DIHOOL DHLCT-150 electric scissor lift table (load capacity 150kg, electric lifting).

3. Key Structure

Folding chassis: It adopts high-strength steel and retractable scissor structure, with a thickness less than 30cm after storage, making it easy to carry with you.

Lifting mechanism: The lifting height of electric models is usually 0.5-1.5m. The protective design includes anti-slip countertops, side baffles and emergency braking devices.

Mobile configuration: ‌Generator wheels or directional wheels are standard for moving on flat ground‌.

4. Typical application scenarios

Logistics and transportation: Quickly load and unload small goods (such as express parcels, equipment parts), reducing forklift dependence.

Project emergency repair: In conjunction with truck crane equipment, it is used for high-altitude operations such as power repair and pipeline installation.

Commercial services: cargo lifting and lowering demand in catering logistics vehicles, exhibition material transportation and other scenarios.

Home decoration: Quickly load and unload building materials and furniture, saving time and effort, safe and reliable.

5. How to use electric scissor lift table to make a lifting trolley that can be put on the car

(1). Use the ‌folding scissors arm as the lifting core component, and the platform is vertically lifted and lowered through the linear actuat to ensure that height adjustment is completed in a limited space.

(2). The chassis must be adapted to the size of the vehicle cargo box, be welded with high-strength steel, and a folded structure is designed to reduce the storage thickness.

(3). The power system can be hydraulic or electric. The electric drive can be driven by a battery + gear motor, which supports remote control operation and improves flexibility in operation.

(4). Vehicle integration solution: Preinstall slides or fixed snaps at the bottom of the truck cargo box to ensure that the lifting platform can be quickly installed/disassembled.

For minivans (such as vans), lightweight scissor structures (load capacity ≤500kg) need to be customized, and the push rod and battery layout are optimized to save space.

(5). Function expansion: Add anti-fall locking device: lock the lifting height through mechanical pins or solenoid valves to prevent accidental falls.

The countertop can be designed to be extensible (such as 90x60cm→120x80cm), which is suitable for loading and unloading needs of different sizes.
