DHLC800-500U Electric Lift Table Legs 1V1 Hall

Model:
  • 500U
Color:
  • Black
  • Grey
  • White

About this item

1. DHLC800 Electric Lifting Table Legs: For versatile applications

2. Speed 25MM/S: Moves at 25MM/S speed

3. Hall Sensor & Infinite Switch: Equipped with Hall sensor and infinite switch

4. 2/3 Columns, Multiple Strokes: Choose from 2 or 4 columns, with 500MM/650MM/900MM stroke options. Suitable for various settings like furniture desks, industrial lift tables, photography tables, labs, and TV lifts.

Product Description

PRODUCT DESCRIPTION

DHLC800 electric lifting column, maximum load 100kg, speed 25MM/S, built-in Hall sensor, infinite switch, need to be controlled by Hall controller. The electric lifting column is divided into 2 columns and 3 columns, and the stroke is divided into 500MM/650MM
Suitable for furniture desks, industrial lift tables, photography tables, laboratory lift tables, TV lifts and other places

TECHNICAL PARAMETERS

Model500U
Initial Height660MM
Final Height1160MM
Stroke Length500MM
Section2
Input VoltageDC24V~DC30V
Load Pull Capacity(N)800N/1000N
Load Push Capacity(N)800N/1000N
Self-locking Capacity(N)800N/1000N
Maximum Power55W
Maximum Speed  25MM/S
ColorRAL9005(Black)/RAL7045(Gray)/ RAL9016(White)
Usage Frequency10% Work System, Maximum 1 Hour Continue Working
Ambient Temperature-10℃ to 60℃
Optional FeaturesHall Sensor
Limit SwitchesNone
Install ScrewsM6*16MM, If the screw is too long, it will damage the motor
Rated Working Capacity80% of Maximum Load, Unable to maintain maximum load operation for a long time
Note

2 columns lifting system and 4 columns lifting system,
any columns cannot exceed 100KG load and needs to be kept fixed
