PRODUCT DESCRIPTION
DIY-40GZ495 reciprocating motors are considered to be sensitive, stable and reliable, noiseless, small in size, light in weight, large in pushing and pulling force, low in energy consumption and low in price.The electric Linear Actuator takes the motor as the power source, drives a pair of screw rod and nut to drive through a pair of gears to change the transmission speed, and converts the rotary motion of the motor into linear motion.
TECHNICAL PARAMETERS
| Voltage | DC24V | |||||||||||||||
| No-load Revolutions (R/MN) | 8 | 10 | 13 | 20 | 27 | 36 | 55 | 60 | 70 | 80 | 120 | 160 | 220 | 250 | 280 | 470 |
| No-load Current (A) | 0.12 | 0.12 | 0.2 | 0.15 | 0.2 | 0.2 | 0.12 | 0.15 | 0.15 | 0.15 | 0.15 | 0.25 | 0.2 | 0.2 | 0.3 | 0.3 |
| Load Revolution (R/MIN) | 5.3 | 6.8 | 8.7 | 14.7 | 20 | 26.6 | 41 | 46 | 52 | 56 | 75 | 110 | 173 | 168 | 198 | 390 |
| Load Current (A) | 0.52 | 0.55 | 1.02 | 1.39 | 1.4 | 1.39 | 0.68 | 0.75 | 0.7 | 0.69 | 0.8 | 1.4 | 1.4 | 1.4 | 1.4 | 1.5 |
| Load Torque (KG.CM) | 35 | 30 | 50 | 18 | 30 | 22 | 8 | 14 | 6 | 5 | 4 | 6 | 5 | 3.5 | 3 | 1.5 |
| Load Power (W) | 12.48 | 13.2 | 24.48 | 33.36 | 33.36 | 33.36 | 16.32 | 18 | 16.8 | 16.56 | 19.2 | 33.6 | 33.6 | 33.6 | 33.6 | 35 |
| 30MM Stroke Load Torque (KG) | 8.17 | 7.00 | 11.67 | 4.20 | 7.00 | 5.13 | 1.87 | 3.27 | 1.40 | 1.17 | 0.93 | 1.40 | 1.17 | 0.82 | 0.70 | 0.35 |
| 50MM Stroke Load Torque (KG) | 4.55 | 3.90 | 6.50 | 2.34 | 3.90 | 2.86 | 1.04 | 1.82 | 0.78 | 0.65 | 0.52 | 0.78 | 0.65 | 0.46 | 0.39 | 0.2 |
| 70MM Stroke Load Torque (KG) | 3.00 | 2.57 | 4.29 | 1.54 | 2.57 | 1.89 | 0.69 | 1.20 | 0.51 | 0.43 | 0.34 | 0.51 | 0.43 | 0.30 | 0.26 | 0.13 |
