PRODUCT DESCRIPTION
DHLCEY mobile tatami electric lift, aluminum column width is 113/104/95MM 3 sections, panel width is 160*160*5MM, mobile tray is made of high hardness resin material, load capacity can reach 300kg, 4 silent roller, This mobile desk is best choice for home and office.
This mobile electric lift has a maximum load capacity of 200kg, maximum speed of 20MM/S, built-in limit switch, it will automatically power off when it rises to the highest position, built-in self-locking mechanism, and the self-locking force of 2000N will not fall after power off.
TECHNICAL PARAMETERS
| Model | DHLCE310Y | ||
| Panel Size | 160*160 | ||
| Initial Height H (MM) | 400 | ||
| Final Height FH(MM) | 760 | ||
| Stroke Length S (MM) | 360 | ||
| Section | 3 | ||
| Voltage | DC24-32V/DC12~19V/Hal 24-32V | ||
| Speed | 5MM/S | ||
| Max Load Capacity | 150KG | ||
| Operating Temperature | 0-40°C | ||
| Limit Switches | Built-in | ||
| Operating Frequency | 10% Work System, Maximum 1 Hour Continue Working | ||
| Color | Silver White | ||
| Material | Body Aluminum ，Panel Iron | ||
| *Other specifications, aluminum shell color, and connection Panel Size can be customized. | |||
OUTLINE DIMENSION DRAWING
